2'' Semiconductor Silicon Wafer Thickness 279μm

Name: 2'' Semiconductor Silicon Wafer Thickness 279μm
Brand: Shanghai GaNova Electronic Information Co., Ltd.
SKU: JDCD06-001-002
Price: 1,000.00 USD
Availability: InStock

All Products

GaN Epitaxial Wafer
(65)

SiC Epitaxial Wafer
(39)

GaAs Epi Wafer
(15)

CVD Diamond Substrates
(15)

Rapid Thermal Annealing System
(2)

Hall Effect Sensor Tester
(3)

Aluminum Nitride Wafer
(21)

Laser Diode Chip
(10)

Silicon Carbide Crystal
(12)

Ga2O3 Wafer
(13)

Silicon Wafer
(26)

Sapphire Wafer
(19)

Patterned Sapphire Substrates
(10)

Wafer Holder
(1)

Wafer Dicing Machine
(5)

Certification

I'm Online Chat Now

2'' Semiconductor Silicon Wafer Thickness 279μm

Large Image : 2'' Semiconductor Silicon Wafer Thickness 279μm

Product Details:

Place of Origin:	Suzhou China
Brand Name:	GaNova
Certification:	UKAS/ISO9001:2015
Model Number:	JDCD06-001-002

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Delivery Time:	3-4 week days
Payment Terms:	T/T
Supply Ability:	50000pcs/month

Contact Now

2'' Semiconductor Silicon Wafer Thickness 279μm

Description

Diameter:	2"	Orientation:	<1-0-0>,<1-1-1>,<1-1-0>
Type/Dopant:	P Type/Boron,N Type/Phos,N Type/As, N Type/Sb	Thickness(μm):	279
Thickness Tolerance:	Standard ± 25μm,Maximum Capabilities ± 5μm	Resistivity:	0.001-100 Ohm-cm
Surface Finished:	P/E,P/P,E/E,G/G	TTV(μm):	Standard <10 μm,Maximum Capabilities<5 μm
Bow/Warp:	Standard <40 μm,Maximum Capabilities<20 μm	Particle:	<10@0.5μm; <10@0.3μm; <10@0.2μm;
Highlight:	2'' semiconductor silicon wafer , N Type silicon epi wafer , n doped silicon wafer 279um

2-Inch Silicon Wafer Thickness(μm)279 Resistivity 0.001-100 Ohm-cm

2-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices

Overview

Few of us have a chance to encounter an actual silicon wafer in daily life. This ultra-flat disk is polished to a mirror-like surface, and made as free as possible of tiny surface irregularities, making it the flattest object in the world. It is also ultra-clean, virtually free of microparticles and other impurities. These qualities are necessary so it can be used as the substrate material of today's state-of-the-art semiconductors.

Specification

silicon wafer
Diameter	2"/3"/4"/5"/6"/8"/12"
Grade	Prime
Growth Method	CZ
Orientation	<1-0-0>,<1-1-1>,<1-1-0>
Type/Dopant	P Type/Boron,N Type/Phos,N Type/As, N Type/Sb
Thickness(μm)	279/380/525/625/675/725/775
Thickness Tolerance	Standard ± 25μm,Maximum Capabilit/ies ± 5μm
Resistivity	0.001-100 ohm-cm
Surface Finished	P/E,P/P,E/E,G/G
TTV(μm)	Standard <10 μm,Maximum Capabilities<5 μm
Bow/Warp	Standard <40 μm,Maximum Capabilities<20 μm
Particle	<10@0.5μm; <10@0.3μm; <10@0.2μm;

About Us

We specialize in processing a variety of materials into wafers, substrates and customized optical glass parts.components widely used in electronics, optics, opto electronics and many other fields. We also have been working closely with many domestic and oversea universities, research institutions and companies, provide customized products and services for their R&D projects. It's our vision to maintaining a good relationship of cooperation with our all customers by our good reputations.
