Semiconductor Compound 2inch GaAs Epi Wafer GaAs Si Wafer UKAS

Large Image : Semiconductor Compound 2inch GaAs Epi Wafer GaAs Si Wafer UKAS

Product Details:

Place of Origin:	Suzhou China
Brand Name:	GaNova
Certification:	UKAS/ISO9001:2015
Model Number:	JDCD10-001-002

Payment & Shipping Terms:

Packaging Details:	Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Delivery Time:	3-4 week days
Payment Terms:	T/T
Supply Ability:	10000pcs/month

Contact Now

Semiconductor Compound 2inch GaAs Epi Wafer GaAs Si Wafer UKAS

Description

Product Name:	GaAs (100) Undoped Substrates	Dopant:	GaAs-Si
Orientation Angle:	0°	OF Orientation:	EJ[0-1-1]±0.5°
OF Length (mm):	17±1	IF Orientation:	EJ[0-11]±0.5°
Highlight:	GaAs Epi Wafer UKAS , 2inch GaAs Si Wafer , Semiconductor Gallium arsenide Wafer

GaAs-Si Wafer 2inch GaAs (100) Undoped Substrates (100)15°±0.5° Off Toward<111>A

Overview

Gallium arsenide (chemical formula GaAs) is a semiconductor compound used in some diode s, field-effect transistor s (FETs), and integrated circuit s (ICs). The charge carriers, which are mostly electron s,move at high speed among the atom s. This makes GaAs components useful at ultra-high radio frequencies, and in fast electronic switching applications. GaAs devices generate less noise than most other types of semiconductor components. This is important in weak-signal amplification.

GaAs-Si Wafer
Growth Method	VGF
Conduct Type	S-C-N
Dopant	GaAs-Si
Orientation	(100)15°±0.5° Off Toward<111>A
Orientation Angle	0°
OF Orientation	EJ[0-1-1]±0.5°
OF Length (mm)	17±1
IF Orientation	EJ[0-11]±0.5°
IF Length(mm)	7±1
Diameter(mm)	50.8±0.2
CC(/c.c.)	0.4E18~1E18
Resistivity(ohm.cm)	N/A
Mobility(cm²/v.s)	≥1000
EPD(/cm²)	≤5000
Thickness(um)	350±20
TTV(um)	<10
TTR(um)	<10
Bow(um)	<15
Warp(um)	<15
Surface	Side1:Polished Side2:Etched
Packaging	Cassette or single
