Semi Insulating Aluminum Nitride Wafer AIN On Sapphire Wafer Surface

Large Image : Semi Insulating Aluminum Nitride Wafer AIN On Sapphire Wafer Surface

Product Details:

Place of Origin:	Suzhou China
Brand Name:	GaNova
Certification:	UKAS/ISO9001:2015
Model Number:	JDWY01-001-001

Payment & Shipping Terms:

Packaging Details:	Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Payment Terms:	T/T

Contact Now

Semi Insulating Aluminum Nitride Wafer AIN On Sapphire Wafer Surface

Description

Dimensions:	φ50.8mm±0.1mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0mm	Substrate:	Sapphire(Single Or Double Side Polished)
Conduction Type:	Semi-Insulating	Edge Exclusion Zone:	<2mm
Surface Roughness:	Ra<1.5nm(10*10μm)	Product Name:	Aluminum Nitride Wafer
XRD FWHM Of(002):	≤80arcsec, ≤100arcsec, ≤120arcsec, ≤160arcsec	XRD FWHM Of(102):	≤650arcsec, ≤550arcsec, ≤450arcsec, ≤400arcsec
Highlight:	Semi Insulating Aluminum Nitride Wafer , AIN Substrate UKAS , Aluminum Nitride Wafer ISO

2 Inch Thick Film (1,2)μm AIN On Sapphire Wafer SSP XRD FWHM Of(002)≤80arcsec(102) ≤650arcsec UV Disinfection LED Chip

A thin film of aluminum nitride is a layer of aluminum that is resistant to high temperatures. During high temperatures, this layer of aluminum will help protect the material. In high-pressure environments, it can be unstable. It can withstand a range of temperatures up to 980degC. At lower levels, it can be toxic to humans. It is also used in mobile phones. Its properties are extremely diverse.

Item	AlN-T-C-U-C50
Dimensions	φ50.8 mm±0.1 mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0 mm
Substrate	Sapphire(Single or Double Side Polished)
Thickness	1~5μm
Orientation	C-plane (0001)±1^o
Conduction Type	Semi-Insulating
Crystalline Quality	Thickness	XRD FWHM of(002)	XRD FWHM of(102)
	[1,2)μm	≤80arcsec	≤650arcsec
	[2,3)μm	≤100arcsec	≤550arcsec
	[3,4)μm	≤120arcsec	≤450arcsec
	[4,5)μm	≤160arcsec	≤400arcsec
Edge Exclusion Zone	<2mm
Surface Roughness	Ra<1.5nm(10*10μm)
Package	Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.

About Us

We specialize in processing a variety of materials into wafers, substrates and customized optical glass parts.components widely used in electronics, optics, opto electronics and many other fields. We also have been working closely with many domestic and oversea universities, research institutions and companies, provide customized products and services for their R&D projects. It's our vision to maintaining a good relationship of cooperation with our all customers by our good reputations.

FAQ

Q: Are you trading company or manufacturer ?
We are factory.
Q: How long is your delivery time?
Generally it is 3-5 days if the goods are in stock.
or it is 7-10 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
Payment <=5000USD, 100% in advance.
Paymen >=5000USD, 80% T/T in advance , balance before shippment.
