Power Device 5x10mm2 Un-Doped N-Type Free-Standing GaN Single Crystal Substrate with Resistivity 0.1 Ω·cm and BOW within 10µm

Large Image : Power Device 5x10mm2 Un-Doped N-Type Free-Standing GaN Single Crystal Substrate with Resistivity 0.1 Ω·cm and BOW within 10µm

Product Details:

Place of Origin:	Suzhou China
Brand Name:	GaNova
Certification:	UKAS/ISO9001:2015
Model Number:	JDCD01-001-013

Payment & Shipping Terms:

Packaging Details:	Vacuum packing in a class 10000 clean room environment,in cassettes of 6pcs or single wafer containers.
Delivery Time:	3-4 week days
Payment Terms:	T/T
Supply Ability:	10000pcs/month

Contact Now

Power Device 5x10mm2 Un-Doped N-Type Free-Standing GaN Single Crystal Substrate with Resistivity 0.1 Ω·cm and BOW within 10µm

Description

Dimensions:	5 X 10mm²	Orientation:	(11-22) Plane Off Angle Toward M-axis 0 ±0.5° (11-22) Plane Off Angle Toward C-axis - 1 ±0.2°
TTV:	≤ 10µm	BoW:	- 10µm ≤ BOW ≤ 10µm
Macro Defect Density:	0cm⁻²	Useable Area:	> 90% (edge Exclusion)
Product Name:	(11-22) Face Free-standing GaN Substrates	Dislocation Density:	From1 X10⁵ To 3 X 10⁶cm⁻²
Highlight:	0.1 Ω·cm GaN Single Crystal Substrate , 10µm GaN Single Crystal Substrate , 5x10mm2 GaN Single Crystal Substrate

5*10mm² SP-face (11-12) Un-doped n-type free-standing GaN single crystal substrate Resistivity < 0.1 Ω·cm Power device

Overview
Since the 1990s, it has been used commonly in light emitting diodes (LED). Gallium nitride gives off a blue light used for disc-reading in Blu-ray. Additionally, gallium nitride is used in semiconductor power devices, RF components, lasers, and photonics. In the future, we will see GaN in sensor technology.

(11-22) face Free-standing GaN Substrates
Item	GaN-FS-SP-U-S	GaN-FS-SP-N-S	GaN-FS-SP-SI-S	Remarks: A circular arc angle (R < 2 mm) is used for distinguishing the front and back surface.
Dimensions	5 x 10 mm²
Thickness	350 ±25 µm
Orientation	(11-22) plane off angle toward M-axis 0 ±0.5° (11-22) plane off angle toward C-axis - 1 ±0.2°
Conduction Type	N-type	N-type	Semi-Insulating
Resistivity (300K)	< 0.1 Ω·cm	< 0.05 Ω·cm	> 10⁶ Ω·cm
TTV	≤ 10 µm
BOW	- 10 µm ≤ BOW ≤ 10 µm
Front Surface Roughness	< 0.2 nm (polished); or < 0.3 nm (polished and surface treatment for epitaxy)
Back Surface Roughness	0.5 ~1.5 μm option: 1~3 nm (fine ground); < 0.2 nm (polished)
Dislocation Density	From 1 x 10⁵ to 3 x 10⁶ cm^-2
Macro Defect Density	0 cm^-2
Useable Area	> 90% (edge exclusion)
Package	Packaged in a class 100 clean room environment, in 6 PCS container, under a nitrogen atmosphere

Appendix: The diagram of miscut angle

Power Device 5x10mm2 Un-Doped N-Type Free-Standing GaN Single Crystal Substrate with Resistivity 0.1 Ω·cm and BOW within 10µm 1

If δ₁= 0 ±0.5°, then (11-22) plane off angle toward M-Axis is 0 ±0.5°.

If δ₂= - 1 ±0.2°, then (11-22) plane off angle toward C-Axis is - 1 ±0.2°.
